FEATURES
· Digital passive infrared sensor
· LED indicator
· Adjustable time delay from 20 sec to 30 min
· Manual-On operation
· Photocell version for daylight harvesting
· Universal input voltage
· Replace a standard light or fan
· single-pole switch
PHYSICAL SPECS
· Size 2.50''×1.69 ''×2.0'' (65mm×43mm×50mm)
· Weight: 3.9oz
· Standard Wall Mount
ELECTRICAL SPEC
· Maximum Load
800W@ 120VAC
1200W@ 277VAC
1/6 HP@120VAC
· Frequency: 60 Hz
· Neutral Required
ENVIRONMENTAL SPEC
· Operating Temp: 32° to 131°F (0° to 55°C)
· Storage Temp : 14° to 160°F (-10° to 60°C)
· Relative Humidity: 95% non-condensing
